Aeon 7200A – 3 Gas

1. Gas Delivery System:-
-Double-tube mechanical flowmeter for each gas source, supporting 3-gas configuration (O₂, N₂O, Air).
-Accurate and independent gas flow control for all three gases.

2. User Interface:-
-8.4-inch LCD color touchscreen for operation and monitoring.
-Simultaneous display of ventilation waveforms, loops, set parameters, and monitoring values — all color-coded for clarity.
-Quick, intuitive switching between manual and automatic ventilation via a dedicated switch/button.

3. Ventilation Capabilities:-
-Supports major ventilation modes: IPPV, PCV, SIMV-VC, SIMV-PC, CPAP/PS.
-Minimum tidal volume delivery as low as 20 mL, suitable for infants, pediatric, and adult patients.
-Versatile operation across a wide patient range — from neonates/infants to adults.

4. Breathing System & Absorber:-
-Durable alloy breathing system for long-term reliability.
-Large-capacity CO₂ absorber canister (1.8 L) for extended operating times without frequent changes.

5. Safety & Reliability Features:-
-Comprehensive safety system, including oxygen ratio control (ORC), N₂O cut-off valve, and continuous oxygen concentration monitoring to prevent hypoxic mixtures.
-Automatic Power-On Self-Test (POST) on startup, skippable in emergencies.
-Delayed power-off protection (~10 seconds) to prevent accidental shutdowns.
-Integrated battery backup, providing up to 2 hours of operation during power failure or transport.

6. Optional Upgrades & Extendable Features:-
-Multiple Anaesthetic Gas Monitoring (AGM): Option for multi-agent and CO₂ monitoring (mainstream or sidestream).
-Anesthetic Gas Scavenging System (AGSS): Supports passive or active scavenging.
-Optional integrated suction system for airway management.
-Vaporizer support: Compatible with all common anesthetic agents; supports up to 2 vaporizers via Selectatec mounting.

7. Technical & Operational Specifications:-
-Tidal Volume Range: 20 – 1500 mL
-Ventilation Frequency: 2 – 100 breaths/min
-I:E Ratio: 4:1 to 1:8
-Gas Supply Pressure: 0.28 – 0.6 MPa (280–600 kPa)
-O₂ Flush Flow: 25 – 75 L/min
-Device Dimensions (HxWxD): 1356 × 845 × 620 mm (trolley version)
-Weight: ~110 kg (base unit, without additional attachments)
-Power Supply: AC 100–240 V, 50/60 Hz
-Battery: DC 24 V, 2-hour backup when fully charged
